中华肩肘外科电子杂志 ›› 2026, Vol. 14 ›› Issue (02) : 96 -103. doi: 10.3877/cma.j.issn.2095-5790.2026.02.006

论著

双钢板与髓内钉固定治疗伴肱骨内侧距粉碎性肱骨近端骨折的影像学及临床疗效比较研究
毕春, 吴晓明, 吴剑宏()
  1. 201620 上海交通大学医学院附属第一人民医院创伤临床医学中心
  • 收稿日期:2025-06-15 出版日期:2026-05-05
  • 通信作者: 吴剑宏

A comparative study of imaging and clinical outcomes of double-plate versus intramedullary nail fixation for proximal humeral fractures with medial calcar comminution

Chun Bi, Xiaoming Wu, Jianhong Wu()

  1. Department of Orthopedics Trauma, Trauma Center, Shanghai General Hospital, School of Medicine, Shanghai Jiao Tong University, Shanghai 201620, China
  • Received:2025-06-15 Published:2026-05-05
  • Corresponding author: Jianhong Wu
引用本文:

毕春, 吴晓明, 吴剑宏. 双钢板与髓内钉固定治疗伴肱骨内侧距粉碎性肱骨近端骨折的影像学及临床疗效比较研究[J/OL]. 中华肩肘外科电子杂志, 2026, 14(02): 96-103.

Chun Bi, Xiaoming Wu, Jianhong Wu. A comparative study of imaging and clinical outcomes of double-plate versus intramedullary nail fixation for proximal humeral fractures with medial calcar comminution[J/OL]. Chinese Journal of Shoulder and Elbow(Electronic Edition), 2026, 14(02): 96-103.

目的

评估比较双钢板与髓内钉固定治疗伴肱骨内侧距粉碎性肱骨近端骨折的影像学及临床效果。

方法

回顾性分析2017年1月至2024年7月在本院创伤中心接受手术治疗的46例肱骨近端骨折伴肱骨内侧距粉碎的患者。患者接受了双钢板(n = 24)或髓内钉(n = 22)固定治疗。按照Neer分型,其中二部分骨折16例,三部分骨折30例。致伤原因为:交通伤21例,摔倒17例,高坠8例。在术后1、3、6、12个月门诊随访期间对以上患者进行肩关节X片影像学及临床疗效评估,同时评估患者术后并发症发生情况。功能评估指标包括:肩关节活动度、美国肩肘外科医师协会(American shoulder and elbow surgeons, ASES)评分和Constant-Murley评分以评估肩关节功能。

结果

除1例患者骨折在术后5个月愈合外,其余患者骨折均在术后3个月愈合。双钢板组有2例发生螺钉穿透,进行了翻修手术。两组各有1例患者发生近端螺钉松动,但无需再次手术。两组均未发现肱骨头缺血性坏死。在两组患者术前及术后12个月的影像学检查中,颈干角无显著差异。双钢板组的肩关节活动度、平均ASES评分和Constant-Murley评分均优于锁定髓内钉组,但术后12个月随访时差异无统计学意义。

结论

双钢板与髓内钉固定治疗伴肱骨内侧距粉碎性肱骨近端骨折均可获得满意的治疗效果。两者在关节活动度、ASES和Constant-Murley评分方面没有显著差异。采用髓内钉治疗有发生医源性肩袖损伤的风险,而双钢板固定患者术后肩关节功能恢复呈较好趋势。

Background

Proximal humeral fractures account for approximately 6% of all fractures and are one of the most common fracture types in elderly patients, with about 20% requiring surgical treatment. Locking plates offer advantages such as anatomical-morphology matching, built-in suture holes, and angular stability. In recent years, they have been widely used in the internal fixation treatment of proximal humeral fractures and have achieved good clinical efficacy. However, for proximal humeral fractures with comminuted medial calcar, since the Philos locking plate placed on the lateral side cannot directly perform anatomical reduction on the comminuted medial calcar to provide sufficient support, postoperative complications such as varus deformity, internal fixation failure, and non-union are often prone to occur. In light of this, various methods have been adopted in clinical practice to support and stabilize humeral fractures. The Philos locking plate, placed on the lateral side of the humerus, with its spacing screws, can directly support the crushed medial column of the humerus. However, for petite patients (such as short women), its applicability is often limited. Fibula bone graft support can provide biomechanical strength and shows good mechanical stability. However, once conditions such as humeral head necrosis or obvious greater tuberosity absorption occur, surgical revision becomes significantly more difficult. The double-plate fixation treatment technology of outer PHILOS locking plates combined with auxiliary micro-plates has been widely applied recently. It significantly enhances stability and has a clear therapeutic effect. In addition, as one of the commonly used fixation methods for proximal humeral fractures, intramedullary nail fixation can preserve the blood supply to the humeral head through minimally invasive surgical procedures. Its load-dispersion design and the way the humeral center is fixed give it significant biomechanical advantages in stabilizing medial-compression fractures of the proximal humerus. Although double-plate fixation and intramedullary nail fixation are currently used for proximal humeral fractures with medial calcar comminution, direct comparative evidence remains limited.

Objective

To evaluate and compare the imaging and clinical effects of double plate and intramedullary nail fixation in the treatment of comminuted proximal humeral fractures with medial calcar of the humerus.

Methods

A retrospective analysis was conducted on 46 patients with proximal humeral fractures accompanied by fragmentation of the medial humeral calcar who underwent surgical treatment at the trauma center of our hospital from January 2017 to July 2024. Patients underwent double-plate fixation (n = 24) or intramedullary nails fixation (n = 22). According to the Neer classification, there were 16 cases of two-part fractures and 30 cases of three-part fractures. The causes of injury were as follows: 21 cases of traffic injuries, 17 cases of falls, and 8 cases of falls from heights. During outpatient follow-up at 1, 3, 6, and 12 months after the operation, shoulder joint X-ray imaging and clinical efficacy evaluation were performed for the above patients, and postoperative complications were also evaluated at the same time. Functional assessment indicators include: Shoulder joint range of motion (ROM), the American shoulder and elbow surgeons (ASES) score, and the Constant-Murley score to evaluate shoulder joint function.

Results

Except for one patient whose fracture healed 5 months after the operation, the fractures of the remaining patients all healed 3 months after the operation. In the double-plate group, 2 cases had screw penetration and underwent revision surgery. One patient in each group experienced proximal screw loosening, but no reoperation was required. Ischemic necrosis of the humeral head was not found in either group. In imaging examinations of the two groups of patients before the operation and 12 months after, there was no significant difference in the neck-shaft angle. The shoulder joint range of motion, average ASES score, and Constant-Murley score in the double plate group were all better than those in the locked intramedullary nail group. Still, there was no statistically significant difference at the 12-month follow-up after the operation.

Conclusion

Double plate and intramedullary nail fixation treatment with comminuted proximal humeral fractures of the medial calcar of the humerus can all achieve satisfactory therapeutic effects. There were no significant differences between the two in terms of joint ROM, ASES, and Constant-Murley scores. Intramedullary nail treatment carries the risk of iatrogenic rotator cuff injury, while patients with double plate fixation have better recovery of shoulder joint function after surgery.

图1 男性,43岁,车祸伤致右肱骨近端骨折伴肱骨内侧距损伤 图A-B:术前肩关节正位X线片及术前肩关节三维CT显示:右肱骨近端骨折,骨折累及大结节及肱骨内侧距;图C-D:术后1个月随访肩关节正位X线片及冈上肌出口位片示:肱骨近端骨折复位,钢板固定位置满意;图E-F:术后12个月随访影像显示:肱骨近端骨折愈合,肱骨内侧距恢复支撑,钢板位置稳定
图2 男性,36岁,摔伤致右肱骨近端骨折合并肱骨内侧距粉碎 图A-B:术前肩关节正位X线片及术前肩关节三维CT重建示:右肱骨近端骨折,骨折累及大、小结节及肱骨内侧距区域;图C-D:术后3个月随访,肩关节正位X线片及冈上肌出口位片示:肱骨近端骨折复位,髓内钉固定位置满意;图E-F:术后12个月随访影像显示:肱骨近端骨折愈合,骨痂形成良好,肱骨内侧距恢复支撑,内固定位置稳定
表1 两组患者一般情况
表2 两组患者影像学评估结果
表3 两组二部分肱骨近端骨折患者临床功能评估结果(±s)
表4 两组三部分肱骨近端骨折患者临床功能评估结果(±s
[1]
Ong PW, Lim CJ, Pereira MJ, et al. Achieving satisfactory functional outcomes in conservatively treated proximal humerus fractures: relationship between shoulder range of motion and patient-reported clinical outcome scores[J]. JSES Int, 2024, 8(3):440-445.
[2]
Brorson S, Viberg B, Gundtoft P, et al. Epidemiology and trends in. management of acute proximal humeral fractures in adults: an observational study of 137,436 cases from the Danish National Patient Register, 1996-2018[J]. Acta Orthop, 2022, 93:750-755.
[3]
Iglesias-Rodriguez S, Dominguez-Prado DM, Garcia-Reza A, et al. Epidemiology of proximal humerus fractures[J]. J Orthop Surg Res, 2021, 16(1):402.
[4]
Baker HP, Gutbrod J, Cahill M, et al. Optimal Treatment of Proximal Humeral Fractures in the Elderly: Risks and Management Challenges[J]. Orthop Res Rev, 2023, 15:129-137.
[5]
Sun Q, Wu X, Wang L, et al. The plate fixation strategy of complex proximal humeral fractures[J]. Int Orthop, 2020, 44(9):1785-1795.
[6]
Hernigou P, Hernigou J, Scarlat M. Shoulder Osteonecrosis: Pathogenesis, Causes, Clinical Evaluation, Imaging, and Classification[J]. Orthop Surg, 2020, 12(5):1340-1349.
[7]
Hättich A, Harloff TJ, Sari H, et al. Influence of Fracture Reduction on the Functional Outcome after Intramedullary Nail Osteosynthesis in Proximal Humerus Fractures[J]. J Clin Med, 2022, 11(22):6861.
[8]
Attala D, Primavera M, Di Marcantonio A, et al. The role of minimally invasive plate osteosynthesis(MIPO) technique for treating 3- and 4-part proximal humerus fractures in the elderly - a case study[J]. Acta Biomed, 2021, 92(4):e2021251.
[9]
Greenberg A, Rosinsky PJ, Gafni N, et al. Proximal humeral nail for treatment of 3- and 4-part proximal humerus fractures in the elderly population: effective and safe in experienced hands[J]. Eur J Orthop Surg Traumatol, 2021, 31(4):769-777.
[10]
Xu J, Zhan S, Ling M, et al. How can medial support for proximal humeral fractures be achieved when positioning of regular calcar screws is challenging? Slotting and off-axis fixation strategies[J]. J Shoulder Elbow Surg, 2022, 31(4):782-791.
[11]
Dasari SP, Kerzner B, Fortier LM, et al. Improved outcomes for proximal humerus fracture open reduction internal fixation augmented with a fibular allograft in elderly patients: a systematic review and meta-analysis[J]. J Shoulder Elbow Surg, 2022, 31(4):884-894.
[12]
Sheng N, Wang Q, Chu G, et al. Cancellous bone allograft is comparable to fibular strut allograft for augmentation in three- or four-part proximal humeral fractures[J]. J Shoulder Elbow Surg, 2021, 30(9):2065-2072.
[13]
Seok HG, Park SG. Dual-Plate Fixation for Proximal Humerus Fractures With Unstable Medial Column in Patients With Osteoporosis[J]. J Orthop Trauma, 2023, 37(10):e387-e393.
[14]
Zeng LQ, Chen YF, Jiang YW, et al. A new low-profile anatomic locking plate for fixation of comminuted, displaced greater tuberosity fractures of the proximal humerus[J]. J Shoulder Elbow Surg, 2021, 30(6):1402-1409.
[15]
Li Y, Lu N, Zhang F, et al. Dual Locking Plate Osteosynthesis for 3- or 4-Part Proximal Humeral Fractures Combined with Multiple Fractures of the Greater Tuberosity[J]. Indian J Orthop, 2021, 55(3):695-701.
[16]
Dewarrat A, Terrier A, Barimani B, et al. Comparison of the ALPS and PHILOS plating systems in proximal humeral fracture fixation - a retrospective study[J]. BMC Musculoskelet Disord, 2023, 24(1):371.
[17]
Wang M, Wang X, Cai P, et al. Locking plate fixation versus intramedullary nail fixation for the treatment of multifragmentary proximal humerus fractures(OTA/AO type 11C): a preliminary comparison of clinical efficacy[J]. BMC Musculoskelet Disord, 2023, 24(1):461.
[18]
Congia S, Palmas A, Marongiu G, et al. Is antegrade nailing a proper option in 2- and 3-part proximal humeral fractures?[J]. Musculoskelet Surg, 2020, 104(2):179-185.
[19]
Russo R, Cautiero F, Della Rotonda G. The classification of complex 4-part humeral fractures revisited: the missing fifth fragment and indications for surgery[J]. Musculoskelet Surg, 2012, Suppl 1:S13-19.
[20]
Tanaka Y, Gotani H, Sasaki K, et al. Evaluation of intramedullary nail fixation via the Neviaser portal for proximal humerus fracture[J]. J Clin Orthop Trauma, 2019, 10(3):474-479.
[21]
Boadi PJ, Da Silva A, Mizels J, et al. Intramedullary versus locking plate fixation for proximal humerus fractures: indications and technical considerations[J]. JSES Rev Rep Tech, 2024, 4(3):615-624.
[22]
Lambert S, Brorson S, Joeris A, et al. International consensus for a core radiological monitoring protocol of proximal humerus fractures[J]. Injury, 2022, 53(10):3326-3331.
[23]
Xiang H, Wang Y, Yang Y, et al. Anatomical study for the treatment of proximal humeral fracture through the medial approach[J]. J Orthop Surg Res, 2022, 17(1):35.
[24]
Ren H, Wu L, Zhang X, et al. The effect of integrity of lesser tuberosity-medial calcar on postoperative outcome in the proximal humeral fracture[J]. J Orthop Surg Res, 2023, 18(1):363.
[25]
Ker AM, Veen EJD, Maharaj JC, et al. Pedicled-lesser tuberosity osteotomy for glenohumeral joint exposure: a technical note and case report highlighting its use in allograft reconstruction of a large engaging reverse Hill-Sachs lesion after posterior shoulder dislocation[J]. JSES Rev Rep Tech, 2021, 1(3):224-228.
[26]
Agarwalla A, Lu Y, Reinholz AK, et al. Identifying clinically meaningful subgroups following open reduction and internal fixation for proximal humerus fractures: a risk stratification analysis for mortality and 30-day complications using machine learning[J]. JSES Int, 2024, 8(5):932-940.
[27]
Saber AY, Said UN, Abdelmonem AH, et al. Surgical Fixation of Three- and Four-Part Proximal Humeral Fractures Using the Proximal Humeral Interlocking System Plate[J]. Cureus, 2022, 14(5):e25348.
[28]
Ziegler P, Maier S, Stuby F, et al. Clinical Outcome of Carbon Fiber Reinforced Polyetheretherketone Plates in Patients with Proximal Humeral Fracture: One-Year Follow-Up[J]. J Clin Med, 2023, 12(21):6881.
[29]
Kim BS, Kim DH, Choi JH, et al. Is Device Removal Necessary after Fixed-Angle Locking Plate Osteosynthesis of Proximal Humerus Fractures?[J]. Medicina(Kaunas), 2022, 58(3):382.
[30]
Keshav K, Baghel A, Kumar V, et al. Is Minimally Invasive Plating Osteosynthesis Better Than Conventional Open Plating for Humeral Shaft Fractures? A Systematic Review and Meta-Analysis of Comparative Studies[J]. Indian J Orthop, 2021, 55(Suppl 2):283-303.
[31]
Van Bergen SH, Mahabier KC, Van Lieshout EMM, et al. Humeral shaft fracture: systematic review of non-operative and operative treatment[J]. Arch Orthop Trauma Surg, 2023, 143(8):5035-5054.
[32]
Wang Y, Chen H, Wang L, et al. Comparison between osteosynthesis with interlocking nail and minimally invasive plating for proximal- and middle-thirds of humeral shaft fractures[J]. Int Orthop, 2021, 45(8):2093-2102.
