中华肩肘外科电子杂志 ›› 2025, Vol. 13 ›› Issue (04) : 226 -231. doi: 10.3877/cma.j.issn.2095-5790.2025.04.006

论著

带袢钛板与锁骨钩板治疗肩锁关节Rockwood Ⅲ、Ⅳ型脱位的对比研究
高晓红, 王雪臣, 刘世炎, 孟小光, 徐凤松, 史福东()
  1. 063000 唐山市人民医院骨科
  • 收稿日期:2025-06-26 出版日期:2025-11-05
  • 通信作者: 史福东

A comparative study on the treatment of Rockwood type Ⅲ and Ⅳ dislocation of the acromioclavicular joint with titanium plates with loops and clavicular hook plates

Xiaohong Gao, Xuechen Wang, Shiyan Liu, Xiaoguang Meng, Fengsong Xu, Fudong Shi()

  1. Department of Orthopedics,Tangshan People's Hospital, Tangshan 063000, China
  • Received:2025-06-26 Published:2025-11-05
  • Corresponding author: Fudong Shi
引用本文:

高晓红, 王雪臣, 刘世炎, 孟小光, 徐凤松, 史福东. 带袢钛板与锁骨钩板治疗肩锁关节Rockwood Ⅲ、Ⅳ型脱位的对比研究[J/OL]. 中华肩肘外科电子杂志, 2025, 13(04): 226-231.

Xiaohong Gao, Xuechen Wang, Shiyan Liu, Xiaoguang Meng, Fengsong Xu, Fudong Shi. A comparative study on the treatment of Rockwood type Ⅲ and Ⅳ dislocation of the acromioclavicular joint with titanium plates with loops and clavicular hook plates[J/OL]. Chinese Journal of Shoulder and Elbow(Electronic Edition), 2025, 13(04): 226-231.

目的

通过回顾性研究比较锁骨钩板与带袢钛板治疗Rockwood Ⅲ、Ⅳ型肩锁关节脱位的临床疗效。

方法

纳入2020年3月至2023年3月于唐山市第二医院和唐山市人民医院接受锁骨钩板或者带袢钛板治疗的Rockwood Ⅲ、Ⅳ型患者共55例,对患者的手术时间、关节功能评分、术后疼痛和并发症方面进行对比。

结果

带袢钛板组平均手术时间为(61.67±6.60)min,显著长于钩板组(38.51±5.61)min(P<0.05)。术后视觉模拟评分方面,带袢钛板组为(2.07±1.14)分,高于钩板组的(1.20±0.96)分(P<0.05)。肩关节功能评估显示,带袢钛板组在前屈上举(142.16° vs 137.22°)和外展上举(142.71° vs 106.31°)活动度方面均显著优于钩板组(P<0.05)。Constant-Murley评分带袢钛板组(89.86±4.41)分明显高于钩板组(73.43±6.63)分(P<0.05)。并发症方面,带袢钛板组出现1例复位丢失,钩板组发生2例肩峰下撞击和3例肩峰下溶解,组间差异具有统计学意义(P<0.05)。两组术中出血量无显著差异,带袢钛板组(57.10±6.11)ml,钩板组(53.90±5.57)ml,P>0.05。

结论

带袢钛板手术方法治疗Rockwood Ⅲ、Ⅳ型肩锁关节脱位在临床疗效中优于锁骨钩板手术方法。

Background

Acromioclavicular joint dislocation (AC dislocation) is a common bone and joint injury in clinical practice, with an annual incidence rate of 18 per 10,000. It is more prevalent in men aged 20 to 39. Traffic accidents and sports activities are the main causes of the disease. The trauma mechanism is the injury of the coracoclavicular ligament caused by the direct or indirect stress transmission of the shoulder to the acromioclavicular joint. This then leads to dislocation of the acromioclavicular joint and the loss of its normal anatomical alignment structure. Most patients with acromioclavicular joint dislocation require surgical treatment. Currently, the main surgical methods are clavicular hook plate internal fixation and titanium plate internal fixation with loops. The clavicular hook plate is a classic surgical treatment method. Its principle is to restore the normal anatomical alignment of the acromioclavicular joint through open reduction, and then place the hook plate under the acromion. The upward displacement of the clavicular side is corrected and fixed through the lever principle. Based on the long-term follow-up results, Liu Zhenhuang, Zhou Haibing, Hu Yongbin et al. believe that the hook plate remains an effective surgical method for treating acromioclavicular joint dislocation. However, compared with other methods, the clinical effect of clavicular hook plate surgery is associated with complications such as subacromial synovitis, subacromial impaction, and subacromial surface wear. The Fixation of titanium plates with loops is Elastic Fixation. Its main therapeutic principle is to use loops and high-intensity risks to restore the stability of the coracoclavicular ligament and thereby maintain the reduction of the acromioclavicular joint. This surgical procedure can be performed under arthroscopy or, under the surveillance of image enhancement, through small incisions around the coracoid process for reduction and fixation. The results of the clinical report show that it has the advantages of small surgical trauma, reliable fixation, simple operation, and no need for secondary removal of internal fixation. Of course, titanium plates with loops also have complications such as bone tract fractures and loss of reduction. At present, there is still controversy over the clinical efficacy comparison of the two surgical methods in Rockwood type Ⅲ and type Ⅳ.

Objective

To compare the clinical efficacy of clavicular hook plates and titanium plates with loops in the treatment of Rockwood typeⅢ andⅣ acromioclavicular joint dislocation through a retrospective study.

Methods

A total of 55 patients with Rockwood type Ⅲ and Ⅳ who received clavicular hook plate or titanium plate with loop treatment at Tangshan Second Hospital and Tangshan People's Hospital from March 2020 to March 2023 were included. The operation time, joint function score, postoperative pain and complications of the patients were compared.

Results

The average operation time of the loop titanium plate group was (61.67±6.60) minutes, which was significantly longer than that of the hook plate group (38.51±5.61) minutes (P<0.05). In terms of the postoperative VAS score, the group of the titanium plate with loops was (2.07±1.14) points, which was higher than that of the hook plate group (1.20±0.96) points (P<0.05). The assessment of shoulder joint function showed that the titanium plate with loops group with loops was significantly superior to the hook plate group in terms of range of motion in both forward flexion and elevation (142.16° vs 137.22°) and abduction and elevation (142.71° vs 106.31°) (P<0.05). The Constant-Murley score of the titanium plate with loops group (89.86±4.41) points was significantly higher than that of the hook plate group (73.43±6.63) points (P<0.05). In terms of complications, one case of reduction loss occurred in the titanium plate group with loops, while two cases of subacromial impaction and three cases of subacromial dissolution occurred in the hook plate group. The differences between the groups were statistically significant (P<0.05). There was no significant difference in intraoperative blood loss between the two groups [titanium plate with loops group (57.10±6.11) ml, hook plate group (53.90±5.57) ml, P>0.05].

Conclusion

The surgical method with loop titanium plate for treating Rockwood type Ⅲ and Ⅳ acromioclavicular joint dislocation is superior to the hook plate surgical method in clinical efficacy.

图1 钩板组术前(图A)、术后(图B)X线片
图2 带袢钛板术中(图A)与术后(图B)
图3 带袢钛板组术前(图A)、术后(图B)X线片
表1 两组患者手术相关资料比较(±s)
表2 两组患者功能比较(±s)
表3 两组患者并发症方面比较
[1]
Chillemi C, Franceschini V, Dei Giudici L, et al. Epidemiology of isolated acromioclavicular joint dislocation [J]. Emerg Med Int, 2013, 2013:171609.
[2]
刘镇煌,黄长明,范华强,等.肩锁关节脱位钩板固定的并发症与对策[J].中国矫形外科杂志,2023,31(2):111-116.
[3]
周海兵,罗志军,张善征,等.两种钢板内固定治疗创伤性肩锁关节脱位的疗效比较[J].临床骨科杂志,2025,28(2):224-227.
[4]
胡勇斌,万春飞,张利勇,等.改良带袢钛板悬吊固定治疗肩锁关节脱位的近中期疗效[J].中国临床医学,2023,30(6):1015-1020.
[5]
Fraser-Moodie JA, Shortt NL, Robinson CM. Injuries to the acromioclavicular joint [J]. J Bone Joint Surg Br200890(6):697-707.
[6]
Kim SH, Koh KH. Treatment of Rockwood TypeⅢ Acromioclavicular Joint Dislocation [J]. Clin Shoulder Elbow, 2018, 21(1):48-55.
[7]
Chen CH, Dong QR, Zhou RK, et al. Effects of hook plate on shoulder function after treatment of acromioclavicular joint dislocation [J]. Int J Clin Exp Med, 2014, 7(9):2564-2570.
[8]
陈利,王锦海,董浩男,等.锁骨钩板在肩锁关节脱位治疗中的不足及改良[J/CD].中华肩肘外科电子杂志,2024,12 (4):377-381.
[9]
Shih CM, Huang KC, Pan CC, et al. Biomechanical analysis of acromioclavicular joint dislocation treated with clavicle hook plates in different lengths [J]. Int Orthop, 2015, 39(11):2239-2244.
[10]
Xu D, Luo P, Chen J, et al. Outcomes of surgery for acromioclavicular joint dislocation using different angled hook plates: a prospective study [J]. Int Orthop, 2017, 41(12):2605-2611.
[11]
刘畅,王跃,何永兵,等.不同长度及材质锁骨钩板内固定治疗肩锁关节脱位三维有限元分析[J]. 中国骨与关节损伤杂志,2023,38(3):303-305.
[12]
何洁铭,王嘉.急性肩关节脱位Rockwood Ⅲ~Ⅴ型手术治疗中锁骨钩板和袢钛板应用效果的比较分析[J/CD].中华肩肘外科电子杂志,2020,8 (1):11-15.
[13]
Gupta S, Jangir L, Meena RP, et al. Acromioclavicular Joint Dislocation RePair Using Double Endobutton Technique: Analysis of Functional Outcome[J]. Asian J Orthop Res,2023,6(2):64-72.
[14]
何国文,高大伟,陈亮,等.Endobutton带袢钛板内固定与锁骨钩板内固定治疗Rockwood Ⅲ型肩锁关节脱位的中长期疗效观察[J/CD].中华肩肘外科电子杂志,2022,10 (2):105-110.
[15]
刘挺,周彬,王冶,等.改良TightRoPe袢钛板解剖重建喙锁韧带治疗Rockwood Ⅲ~Ⅴ型肩锁关节脱位[J].中国骨与关节损伤杂志,2024,39(9):924-927.
[16]
Sun LJ, Lu D, Tao ZY, et al. Analysis of risk factors for loss of reduction after acromioclavicular joint dislocation treated with the suture-button [J]. J Orthop Sci, 2019, 24(5):817-821.
[17]
季斌,冯萍,赵增斌,等. TightRoPe与钩板治疗肩锁关节脱位的比较[J]. 中国矫形外科杂志,2022,30(10):877-882.
[18]
Vajapey SP, Bong MR, Peindl RD, et al. Evaluation of the Clavicle Hook Plate for Treatment of Acromioclavicular Joint Dislocation: A Cadaveric Study [J]. J Orthop Trauma, 2020, 34(1):e20-e25.
[19]
王斌,高益,沈鹏飞,等. 改良双Endobutton钢板技术治疗Tossy Ⅲ型肩锁关节脱位[J]. 实用医学杂志,2014,30(2):222.
[20]
邱东新,赖敏锋,杨显鑫. Nice结联合锁骨小骨道双袢钛板内固定治疗急性肩锁关节脱位的疗效观察[J]. 中国骨与关节损伤杂志,2023,38(9):971-973.
[21]
Taleb H, Afshar A, Shariyate MJ, et al. Comparison of Short-Term Clinical Outcomes of Hook Plate and Continuous Loop Double Endobutton Fixations in Acute Acromioclavicular Joint Dislocation [J]. Arch Bone Jt Surg, 2019, 7(6):545-550.
[22]
Drampalos E, Oikonomidis L, Oakley J, et al. Management of acromioclavicular joint dislocation by double Endobutton technique[J]. Inter J Orthop Sci,2022,8 (3):334-337.
[23]
洪乐金,张晓农,孙忠良,等. 锁骨钩板与Endobutton带袢钛板治疗肩锁关节脱位的效果对照[J].中国医疗器械信息,2024,30(4):69-71.
[24]
刘磊,年坤党,陆超峰,等.钩板治疗肩锁关节脱位内固定取出术后肩锁关节复位丢失的影响因素分析[J].全科医学临床与教育,2023,21(10):880-883.
[25]
邱东新,赖敏锋,王云清.改良袢钛板与钩板内固定治疗急性肩锁关节脱位的疗效比较[J].中国骨与关节损伤杂志,2024,39(9):974-977.
